1. Support for 9th and 8th Generation Intel^® Core™ i9 processors/ Intel^® Core™ i7 processors/ Intel^® Core™ i5 processors/ Intel^® Core™ i3 processors/ Intel^® Pentium^® processors/ Intel^® Celeron^® processors in the LGA1151 package
2. La Cache L3 varia da CPU a CPU

(Please refer “CPU Support List” for more information.)

1. Intel^® B365 Express Chipset

1. 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory
2. Architettura di memoria a doppio canale
3. Support for DDR4 2666/2400/2133 MHz memory modules
4. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
6. Supporta le memorie dotate di Profilo XMP
7. * To support 2666 MHz or XMP memory, you must install a 9th or 8th Generation Intel® Core™ i9/i7/i5 processor.

((Per maggiori informazioni fare riferimento alla Lista di memorie compatibili))

1. 1 x D-Sub port, supporting a maximum resolution of 1920×1200@60 Hz
2. 1 x DVI-D port, supporting a maximum resolution of 1920×1200@60 Hz
   * The DVI-D port does not support D-Sub connection by adapter.
3. 1 x HDMI port, supporting a maximum resolution of 4096×2160@30 Hz
4. * Support for HDMI 1.4 version and HDCP 2.2.

Support for up to 3 displays at the same time
Maximum shared memory of 1 GB
* Actual support may vary by CPU.

1. Realtek^® ALC887 codec
2. Audio ad alta definizione
3. 2/4/5.1/7.1-channel

   * Per configurare l’ audio 7.1 devi usare un modulo frontale HD e abilitare il Multi Channel Audio dal pannello di controllo dei tuoi driver

4. Supporta uscite S/PDIF

1. Realtek® GbE LAN chip (10/100/1000 Mbit)

1. 1 x Slot PCI Express x16, funzionante a x16
2. * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
3. 1 x PCI Express x1 slot
4. (All of the PCI Express slots conform to PCI Express 3.0 standard.)
5. 1 x PCI Express x4 slot

1. 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support)
2. 6 x SATA 6Gb/s connectors
3. Support for RAID 0, RAID 1, RAID 5, and RAID 10
4. * Refer to “1-7 Internal Connectors,” for the installation notices for the M.2 and SATA connectors.

Intel® Optane™ Memory Ready

1. 6 x USB 3.1 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB headers)
2. 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)

1. 1 x 24-pin ATX main power connector
2. 1 Connettore di Alimentazione ATX ad 8-pin
3. 1 Connettore per Ventola della CPU
4. 2 x sistema di ventilazione
5. 1 x RGB LED strip header
6. 1 x M.2 Socket 3 connector
7. 6 x SATA 6Gb/s connectors
8. 1 x front panel header
9. 1 x front panel audio header
10. 1 x S/PDIF Out header
11. 1 x USB 3.1 Gen 1 header
12. 2 x USB 2.0/1.1 headers
13. 1 x Trusted Platform Module (TPM) header (2×6 pin, for the GC-TPM2.0_S module only)
    La funzione TPM è opzionale in base alla regolamentazione dei vari stati
14. 1 Porta seriale
15. 1 x parallel port header
16. 1 x Clear CMOS jumper

1. 1 Connessione per Mouse e Tastiera PS/2
2. 1 x Porta D-Sub
3. 1 x Porta DVI-D
4. 1 Porta HDMI
5. 4 x USB 3.1 Gen 1 ports
6. 2 x USB 2.0/1.1 ports
7. 1 Porta RJ-45
8. 3 x audio jacks

1. iTE® I/O Controller Chip

1. Voltage detection
2. Temperature detection
3. Fan speed detection
4. Overheating warning
5. Fan fail warning
6. Fan speed control
7. * Whether the fan speed control function is supported will depend on the cooler you install.

1. 2 x 128 Mbit flash
2. Use of licensed AMI UEFI BIOS
3. Support for DualBIOS™
4. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

1. Support for APP Center
   * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
   3D OSD
   @ BIOS ™
   Auto Green
   Support for Cloud Station
   EasyTune
   Easy RAID
   Fast Boot
   Game Boost
   Supporto alla tecnologia ON/OFF Charge
   Platform Power Management
   RGB Fusion
   Smart Backup
   Smart Keyboard
   Smart TimeLock
   Smart HUD
   Smart Survey
   System Information Viewer
   USB Blocker
2. Supporta il Q-Flash
3. Support for Xpress Install

1. Norton® Internet Security (OEM version)

1. Support for Windows 10 64-bit

1. Micro ATX Form Factor; 22.6cm x 20.5cm

1. A causa delle diverse condizioni di supporto per Linux fornito da fornitori di chipset, scaricare il driver Linux dal sito web fornitori di chipset.
2. Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.
