Scheda madre ASUS P8H67-M EVO LGA 1155 DDR3

Disponibilità:

Esaurito


Intel® Socket 1155 for 2nd Generation Core™ i7/Core™ i5/Core™ i3 Processors

150,00

Esaurito

Specifiche:

  • CPU

    Intel® Socket 1155 for 2nd Generation Core™ i7/Core™
    i5/Core™ i3 Processors
    Supports Intel® 32 nm CPU
    Supports
    Intel® Turbo Boost Technology 2.0
    * The Intel® Turbo Boost
    Technology 2.0 support depends on the CPU types.
  • Chipset

    Intel® H67(B3)
  • Memoria

    4 x DIMM, Max. 32GB, DDR3 1333/1066 Hz Non-ECC, Un-buffered Memory
    Dual
    Channel Memory Architecture
    Supports Intel® Extreme Memory Profile
    (XMP)
    * The XMP support (MAX 1333MHz) is subject to the physical characteristics
    of individual CPUs and the package of DRAM. Please refer to Memory QVL for details.
    *
    According to Intel® SPEC, the Max. 32GB memory capacity can be supported
    with DIMMs of 8GB (or above). ASUS will update QVL once the DIMMs are available
    on the market.
    * Refer to www.asus.com or
    user manual for the Memory QVL (Qualified Vendors Lists).
  • Grafica

    Integrated Graphics Processor
    Multi-VGA output support : HDMI/DVI/RGB/DisplayPort
    ports
    – Supports HDMI with max. resolution 1920 x 1200 @ 60 Hz

    Supports DVI with max. resolution 1920 x 1200 @ 60 Hz
    – Supports RGB with
    max. resolution 2048 x 1536 @ 75 Hz
    – Supports DisplayPort with max. resolution
    2560 x 1600 @ 60 Hz
    Maximum shared memory of 1748 MB
  • Supporto Multi-GPU

    Supports AMD Quad-GPU CrossFireX™ Technology
  • Slot di Espansione

    1 x PCIe 2.0 x16 (blue)
    1 x PCIe 2.0 x16 (x4 mode, black)
    1
    x PCIe 2.0 x1
    1 x PCI
  • Storage

    Intel® H67(B3) chipset :
    2 x SATA 6Gb/s port(s),
    gray
    4 x SATA 3Gb/s port(s), blue
    Support Raid 0, 1, 5, 10
    Marvell
    88SE6111 controller :

    1 x UltraDMA 133/100/66 for up to
    2 PATA devices , navy blue
    1 x Power eSATA 3Gb/s port(s), green
  • LAN

    Realtek® 8111E , 1 x Gigabit LAN Controller(s)
  • Audio

    Realtek® ALC 892 8-Channel High Definition Audio CODEC
    – Supports
    : Jack-detection, Multi-streaming, Front Panel Jack-retasking
    Audio
    Feature :

    – Blu-ray audio layer Content Protection

    Optical S/PDIF out port(s) at back panel
  • IEEE 1394

    VIA® 6315N controller
    2 x IEEE 1394a port(s)
    (1 at mid-board,
    1 at back panel)
  • Porte USB

    ASMedia® USB 3.0 controller :
    2 x USB 3.1 Gen
    1 port(s) (2 at back panel, blue)
    Intel® H67(B3) chipset :
    12
    x USB 2.0 port(s) (4 at back panel, black, 8 at mid-board)
  • Caratteristiche Overclock

    Overclocking Protection :
    – ASUS C.P.R.(CPU Parameter
    Recall)
  • Caratteristiche Speciali

    ASUS TurboV EVO :
    – Auto Tuning
    – TurboV
    – GPU
    Boost with switch
    ASUS EPU :
    – EPU
    – EPU
    switch
    ASUS Power Design :
    – 8 +2 Phase Power Design
    ASUS
    Exclusive Features
     :
    – MemOK!
    – AI Suite II
    – Ai
    Charger+
    – Anti-Surge
    – ASUS UEFI BIOS EZ Mode featuring friendly
    graphics user interface
    ASUS Quiet Thermal Solution :

    Stylish Fanless Design Heat-sink solution
    – ASUS Fan Xpert
    ASUS
    EZ DIY :

    – ASUS CrashFree BIOS 3
    – ASUS EZ Flash 2
    ASUS
    Q-Design :

    – ASUS Q-Slot
    – ASUS Q-DIMM
    – ASUS
    Q-Connector
  • Porte I/O Posteriori

    1 x PS/2 keyboard/mouse combo port(s)
    1 x DVI
    1 x D-Sub
    1 x DisplayPort
    1
    x HDMI
    1 x Power eSATA 3Gb/s
    1 x IEEE 1394a
    1 x LAN (RJ45) port(s)
    2
    x USB 3.1 Gen 1
    4 x USB 2.0
    1 x Optical S/PDIF out
    6
    x Audio jack(s)
  • I/O Interne

    4 x USB 2.0 connector(s) support(s) additional 8 USB 2.0 port(s)
    1 x IDE
    connector(s)
    1 x TPM connector(s)
    1 x COM port(s) connector(s)
    2
    x SATA 6Gb/s connector(s)
    4 x SATA 3Gb/s connector(s)
    1 x IEEE 1394a
    connector(s)
    1 x CPU Fan connector(s)
    1 x Chassis Fan connector(s)
    1
    x Power Fan connector(s)
    1 x S/PDIF out header(s)
    1 x 24-pin
    EATX Power connector(s)
    1 x 8-pin ATX 12V Power connector(s)
    1 x Front
    panel audio connector(s) (AAFP)
    1 x System panel(s) (Q-Connector)
    1
    x MemOK! button(s)
    1 x EPU switch(es)
    1 x GPU Boost switch(es)
    1
    x Clear CMOS jumper(s)
  • Accessori

    User’s manual
    I/O Shield
    1 x UltraDMA 133/100 cable(s)
    2 x SATA
    3Gb/s cable(s)
    2 x SATA 6Gb/s cable(s)
    1 x Q-connector(s) (2 in 1)
    1
    x 2-port USB and eSATA module(s)
  • BIOS

    32 Mb Flash ROM , EFI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.5, ACPI 2.0a, Multi-language
    BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3
  • Gestibilità

    WfM 2.0,DMI 2.0,WOL by PME,WOR by PME,PXE
  • Disco di Supporto

    Drivers
    Anti-virus software (OEM version)
    ASUS Update
    ASUS Utilities
    Ai
    Charger+
  • Dimensioni Scheda

    uATX Form Factor
    9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm )
COD: P8H67-M EVO Categorie: ,
